Double beam UV-Visible Spectrometer
A double beam UV-VIS spectrometer is a type of spectrophotometer used to measure the absorption of ultraviolet (UV) and visible (VIS) light by a sample.
Double beam UV-VIS spectrometers offer high accuracy and precision in absorption measurements, making them valuable tools in various fields such as chemistry, biochemistry, environmental science, and materials science.
Working Principle
The key feature of a double beam spectrometer is its optical setup, which splits the incoming light beam into two paths: the sample beam and the reference beam. The sample beam passes through the sample being analyzed, while the reference beam passes through a reference material (typically the solvent or a similar material without the analyte).
After passing through the sample and reference cells, the light beams are directed to a detector. The detector measures the intensity of light transmitted through the sample and reference cells at each selected wavelength.
Specifications of the instrument
- Company – Shimadzu
- Model – UV- 1800 (115 VAC)
- Wavelength Range – 190 – 1100 nm
- Source Lamp – Deuterium; Tungsten Halogen
- Bandwidth – 1.0 nm
- Sample Types – Liquids
- Internal users & Other Academic Institutes : ₹300/hr
- Industries/Private laboratories : ₹400/hr
-
- The user must fill the requisition form and provide all the sample details. The form should be duly signed by the authorized signatory of the Institute/ Guide/ HOD and emailed to [email protected]. A confirmation mail will be sent by CIF along with a User Id and final amount to be paid for the facility. After the payment, user can submit the samples in person or post the samples on the following address:
Central Instrumentation Facility, B409, K. R. Mangalam University Sohna Road, Gurugram, Haryana, India, PIN 122103
- The user must fill the requisition form and provide all the sample details. The form should be duly signed by the authorized signatory of the Institute/ Guide/ HOD and emailed to [email protected]. A confirmation mail will be sent by CIF along with a User Id and final amount to be paid for the facility. After the payment, user can submit the samples in person or post the samples on the following address:
How to Book
Account details for the payment are
OR
Click on any payment gateway.
A confirmation mail of the payment must be sent to
[email protected] Â with reference code as the subject of the mail.
For any queries regarding the measurements, please contact, Director, CIF, K.R. Mangalam University, Sohna, Gurugram, Haryana, India 122103 on the email [email protected] within 10 days after receiving the results.
All the communication should be addressed to:
Director
Central Instrumentation Facility (CIF)
Room No: B-409, B-Block, K.R. Mangalam University,
Sohna, Gurugram, Haryana, India
PIN 122103
E-mail:Â Â Â cif@krmangalam.edu.in
