LCR Meter

LCR Meter measures the electric properties such as capacitance, inductance and resistance etc. of a material as a function of temperature and frequencies.

Working Principle

Specifications of the instrument

  • Company – nF Corporation
  • Model – Zm2376
  • Modes – 2 Probe
  • Frequency range – 1 mHz to 5.5 MHz
  • Max. Measurement speed – 2ms
  • Sample Types – Pellets, Membranes

  • Internal users & Other Academic Institutes : ₹350/hour
  • Industries/Private laboratories : ₹500/hour


Download SOP
    • The user must fill the requisition form and provide all the sample details. The form should be duly signed by the authorized signatory of the Institute/ Guide/ HOD and emailed to [email protected]. A confirmation mail will be sent by CIF along with a User Id and final amount to be paid for the facility. After the payment, user can submit the samples in person or post the samples on the following address:
      Central Instrumentation Facility, B409, K. R. Mangalam University Sohna Road, Gurugram, Haryana, India, PIN 122103

How to Book

Account details for the payment are

payment


OR

paytm
gpay
amazon pay
phonepe
card
net-banking

Click on any payment gateway.

For any queries regarding the measurements, please contact, Director, CIF, K.R. Mangalam University, Sohna, Gurugram, Haryana, India 122103 on the email [email protected] within 10 days after receiving the results.
