Central Instrumentation Facility (CIF) is an Integral part of K.R Mangalam University. CIF is a modern lab equipped with advanced analytical instruments such as FTIR (Fourier-Transform Infrared Spectrometer), UV-VIS (Double beam UV-visible spectrometer), LCR meter, DSC/TGA/DTA etc. It provides vital support for research and educational activities, allowing users from different Institutes and Industries to access these sophisticated tools and ensures that the facility’s resources are available to a broad range of researchers and students. The CIF endeavors to foster scientific innovation and enhance the quality of research.
Objectives
Provide access to advanced scientific instruments and equipment for researchers and students in Basic Sciences, Medical & Allied Sciences & Multidisciplinary Sciences.
Facilitate high-quality research by offering technical assistance and training on the use of instruments.
Promote interdisciplinary collaboration and innovation by bringing together researchers from different fields.
Innovation Hub for Scientific Excellence
K.R. Mangalam University boasts many specialised research laboratories, each equipped with modern technology to support a wide array of academic and scientific inquiries. Our labs cater to diverse disciplines, enabling groundbreaking research and innovation.
At the heart of our research infrastructure is the Central Instrumentation Facility (CIF). This premier facility is a resource hub for our researchers, providing access to high-end instruments for advanced experimental and analytical work. Key instruments available at CIF include FTIR.
Message of Director
Â
Central Instrumentation Facility (CIF), a hub of cutting-edge instrumentation and technical expertise aimed at advancing your research endeavors. At CIF, our mission is to provide access to state-of-the-art instruments and facilities, empowering researchers to conduct high-quality research across various disciplines. Whether you’re delving into materials science, biological research, or engineering innovations, CIF is here to support Researchers at every step of the way. As researchers, we understand the importance of reliable and precise instrumentation in driving scientific discovery. Therefore, CIF is equipped with the latest tools and technologies, carefully maintained to ensure optimal performance and accuracy. Moreover, CIF fosters a collaborative environment where interdisciplinary interactions flourish. We encourage researchers to leverage the expertise of your peers and explore new possibilities through interdisciplinary collaborations facilitated by our facility. Innovation thrives when researchers have access to the right tools and support systems, and CIF is dedicated to being your partner in scientific advancement. Together, let’s push the boundaries of knowledge and make impactful contributions to our respective fields.
Dr. Diwakar Padalia | Director of CIF
Team CIF
Dr. Prabhakar Bhandari (PhD)
Director – Operations & Maintenance
Central Instrumentation Facility (CIF) is an Integral part of K.R Mangalam University. CIF is a modern lab equipped with advanced analytical instruments such as FTIR (Fourier-Transform Infrared Spectrometer), UV-VIS (Double beam UV-visible spectrometer), LCR meter, DSC/TGA/DTA etc. It provides vital support for research and educational activities, allowing users from different Institutes and Industries to access these sophisticated tools and ensures that the facility’s resources are available to a broad range of researchers and students. The CIF endeavors to foster scientific innovation and enhance the quality of research.
Objectives
Provide access to advanced scientific instruments and equipment for researchers and students in Basic Sciences, Medical & Allied Sciences & Multidisciplinary Sciences.
Facilitate high-quality research by offering technical assistance and training on the use of instruments.
Promote interdisciplinary collaboration and innovation by bringing together researchers from different fields.
TGA/DTA/DSC is a thermoanalytical technique which measures heat flow and
weight/mass change of a materials as a function of temperature or time
in a controlled environment. The technique can provide information about
thermal stability, Oxidative stability and decomposition kinematics of
materials. We can identify phase transitions, melting point, enthalpy,
composition etc. of a material by utilizing this instrument. The
technique have applications in understanding the behavior of a wide
variety of materials including polymers, inorganic/organic chemicals,
pharmaceutical drugs, composites and many more.
Working Principle
Thermo-Gravimetric Analysis (TGA)– The sample is heated in
N2environment at a constant rate and the change in the weight of the
substance is recorded as a function of temperature or time.
Differential Thermal Analysis (DTA)- The temperature
difference between the sample and the reference is measured at a
constant heat flow.
Differential Scanning Calorimetric (DSC)- The difference in
heat flow required between the Sample and the reference to keep the
temperature constant, is measured.
Specifications of the instrument
Company - TA Instruments
Model - SDT 650
Temperature Range - Room to 1500°C
Linear Heating rate - 0.1 to 100 C/min
Sample weight capacity -200 mg
Sample Types -Powders, Polymers, Liquids
Measurements – TGA/DTA/DSC
Environment – N2
Fourier-Transform Infrared Spectroscopy is a powerful analytic technique
which is used to obtain Infrared spectrum of absorption or transmission
of a solid, liquid or a gas. The technique can provide information about
organic, polymeric, and, in some cases, inorganic materials. When
infrared radiation falls on a compound, molecular vibration generates
unique absorption patterns and hence different chemical compounds and
their composition can be identified. Due to its accuracy, versatility
and accuracy, this technique have applications in a variety of fields
including Chemical Science, Material Science, Pharmaceuticals,
Environmental Science and forensic Science etc.
Working Principle
The key component of an FTIR spectrometer is the interferometer.
It's used to modulate the infrared radiation, splitting it into two
beams. One beam passes through the sample, while the other doesn't.
The beams are then recombined, and the resulting interference
pattern is analyzed. The interference pattern contains information
about the absorption of infrared radiation by the sample at
different frequencies. A mathematical technique called Fourier
transform is used to convert this pattern into a spectrum, which
represents the intensity of absorption as a function of frequency.
Specifications of the instrument
Company - Thermo Scientific
Model - Nicolet Summit X
Mode - Transmission & ATR
Wavenumber range - 4000-400cm-1
Maximum Resolution - 0.45cm -1
Sample Types - Liquids
A double beam UV-VIS spectrometer is a type of spectrophotometer used to
measure the absorption of ultraviolet (UV) and visible (VIS) light by a
sample. Double beam UV-VIS spectrometers offer high accuracy and
precision in absorption measurements, making them valuable tools in
various fields such as chemistry, biochemistry, environmental science,
and materials science.
Working Principle
The key feature of a double beam spectrometer is its optical setup,
which splits the incoming light beam into two paths: the sample beam
and the reference beam. The sample beam passes through the sample
being analyzed, while the reference beam passes through a reference
material (typically the solvent or a similar material without the
analyte).
After passing through the sample and reference cells, the light
beams are directed to a detector. The detector measures the
intensity of light transmitted through the sample and reference
cells at each selected wavelength.
Specifications of the instrument
Company - Shimadzu
Model - UV- 1800 (115 VAC)
Wavelength Range – 190 - 1100 nm
Source Lamp - Deuterium; Tungsten Halogen
Bandwidth - 1.0 nm
Sample Types - Liquids
LCR Meter measures the electric properties such as capacitance,
inductance and resistance etc. of a material as a function of
temperature and frequencies.
Working Principle
Specifications of the instrument LCR Meter Specifications:
Company - nF Corporation
Model - Zm2376
Modes - 2 Probe
Frequency range - 1 mHz to 5.5 MHz
Max. Measurement speed - 2ms
Sample Types - Pellets, Membranes
Refrigerated Centrifuge
A Refrigerated Centrifuge is an essential tool for different scientific and industrial applications.
It is utilized to separate components in a mixture by applying centrifugal force at a controlled low
temperature. The equipment is used to separate biological samples, proteins or enzymes etc. which
require specific processing temperatures and degrade at high temperatures.
The user must fill the requisition form and provide all the sample details. The form should be duly signed by the authorized signatory of the Institute/ Guide/ HOD and emailed to[email protected]. A confirmation mail will be sent by CIF along with a User Id and final amount to be paid for the facility.
After the payment, user can submit the samples in person or post the samples on the following address:
Central Instrumentation Facility, B409, K. R. Mangalam University,
The user must fill the requisition form and provide all the sample details. The form should be duly signed by the authorized signatory of the Institute/ Guide/ HOD and emailed to[email protected]. A confirmation mail will be sent by CIF along with a User Id and final amount to be paid for the facility.
After the payment, user can submit the samples in person or post the samples on the following address:
Central Instrumentation Facility, B409, K. R. Mangalam University,
For any queries regarding the measurements, please contact, Director, CIF, K.R. Mangalam University, Sohna, Gurugram, Haryana, India 122103 on the email [email protected] within 10 days after receiving the results.
For any queries regarding the measurements, please contact, Director, CIF, K.R. Mangalam University, Sohna, Gurugram, Haryana, India 122103 on the email [email protected] within 10 days after receiving the results.
